Cannondale Moterra Neo Full Suspension Electric E-Mountain Bikes
12 more optionss sold out · Show all
Moterra Neo 3
Breaking Boundaries
A dual-suspension e-mountain bike built to crush boundaries. With its intuitive handling & the power and range of the Bosch 750Wh system, nothing is out of reach.
Where it thrives
Challenging trails, Up and down hills, Out in the elements
What it's built for
Handling, Traction, Efficiency, Durability
Highlights
- Proportional Response Tuned SmartForm Alloy frame / RockShox Yari RC fork, 150mm travel
- Bosch SmartSystem - 750wh battery & Performance CX motor
- Shimano XT/Deore 12-speed drivetrain
Moterra Neo 4 (Obsidian and Tiger Eye)
More Juice, No Excuse
The Moterra packs massive power, range, and silky suspension, handling rugged terrain like a luxury off-roader. Built to go further—faster.
Model Description
Moterra 4 strips things down to the essentials—reliable, rugged, and ready for anything. A SmartForm C1 Alloy frame with a RockShox Deluxe Select shock and rugged Suntour Zeron 36X fork deliver a ride that is balanced, planted and predictable. Bosch’s most powerful CX motor and big 600Wh battery deliver smooth, sustained power, with more than enough range to keep things interesting. A Shimano CUES U6000 drivetrain and Tektro Gemini SL 4-piston brakes handle the stops and shifts, making this an always-game partner for off-road exploration and all-day excursions.
What it's for
Endless spins, uphill wins, and permanent grins on all kinds of trails, from the mild to the wild
Highlights
- A premium SmartForm C1 Alloy frame - light, stiff, and guaranteed for life
- Climb-crushing strength and natural feeling power delivery from Bosch's most powerful motor, the Performance CX
- Interchangeable 600Wh battery provides an ideal balance of range and light weight
- Smooth-riding SR Suntour Zeron 36-X Boost 160mm fork, and RockShox Deluxe Select air shock
- Precise shifting from Shimano’s CUES U6000 LinkGlide 11-speed drivetrain
- Strong, controllable braking from Tektro Gemini SL 4-piston hydraulic disc brakes with 203mm rotors
Moterra Neo 4
Pure Power Metal
An aluminium e-mountain bike with infinite capability for the steepest descents and the hardest climbs - with fully integrated all-mountain e-bike technology.
Where it thrives
In the mountains
What it's built for
Trail-riding fun
Highlights
- SmartForm C2 Alloy frame, 150mm travel / RockShox Recon RL Silver fork, 150mm
- Shimano EP8 drive unit / 630Wh battery
- SRAM SX/NX Eagle 12-speed shifting / TRP Slate 4-piston disc brakes
Moterra Neo 5
Pure Power Metal.
An aluminium e-mountain bike with infinite capability for the steepest descents and the hardest climbs - with fully integrated all-mountain e-bike technology.
Where it thrives
In the mountains
What it's built for
Trail-riding fun
Highlights
- SmartForm C1 Alloy frame, 150mm travel / SR Suntour XCR LO Boost fork
- Shimano Deore 10-speed drivetrain / hydraulic disc brakes
- Shimano STEPS E7000 drive unit / 504Wh battery / Range: up to 100km (60mi)
Moterra Neo Carbon 1
Breaking Boundaries
A dual-suspension e-mountain bike built to crush boundaries. With its intuitive handling & the power and range of the Bosch 750Wh system, nothing is out of reach.
Where it thrives
Challenging trails, Up and down hills, Out in the elements
What it's built for
Handling, Traction, Efficiency, Durability
Highlights
- Proportional Response Tuned carbon frame / RockShox Lyrik Select fork, 150mm travel
- Bosch SmartSystem - 750wh battery & Performance CX motor
- Shimano XTR/XT 12-speed drivetrain
Moterra Neo Carbon 1
Boundless
An e-mountain bike with infinite capability. The shackles are off, go ride the unrideable. Again and again.
Where it thrives
Challenging trails, up and down hills, out in the elements
What it's built for
Traction, speed, handling
Highlights
- Proportional Response Tuned Carbon frame, 160mm / New RockShox Zeb Ultimate 160mm fork
- New SRAM X01/XX1/GX Eagle 12-speed shifting / Magura MT7 4-piston brakes
- Bosch Performance Line CX drive unit / 625Wh battery / Range: up to 102km (63mi)
Moterra Neo Carbon 2
Breaking Boundaries
A dual-suspension e-mountain bike built to crush boundaries. With its intuitive handling & the power and range of the Bosch 750Wh system, nothing is out of reach.
Where it thrives
Challenging trails, Up and down hills, Out in the elements
What it's built for
Handling, Traction, Efficiency, Durability
Highlights
- Proportional Response Tuned carbon frame / RockShox Lyrik Select+ fork, 150mm travel
- Bosch SmartSystem - 750wh battery & Performance CX motor
- Shimano XT/SLX 12-speed drivetrain
Moterra Neo Carbon 2
Boundless
An e-mountain bike with infinite capability. The shackles are off, go ride the unrideable. Again and again.
Where it thrives
Challenging trails, up and down hills, out in the elements
What it's built for
Traction, speed, handling
Highlights
- Proportional Response Tuned Carbon frame, 160mm / New RockShox Zeb Select 160mm fork
- New SRAM GX/NX 12-speed shifting / SRAM Guide RE 4-piston brakes
- Bosch Performance Line CX drive unit / 625Wh battery / Range: up to 102km (63mi)
Moterra Neo Carbon LT 1
Breaking Boundaries
With the new Bosch Performance Line CX & 750Wh battery, getting there was the easy part - now it's time for the fun! With 170mm/165mm of travel, piggy back shock and burly build, it's ready to give as much as you are.
Where it thrives
Whatever and wherever you didn't think possible
What it's built for
Handling, Traction, Efficiency, Durability
Highlights
- Proportional Response Tuned carbon frame, 165mm travel / RockShox Zeb Select+ fork, 170mm travel
- Bosch SmartSystem - 750wh battery & Performance CX motor
- Shimano XT 12-speed drivetrain / SRAM Code RSC 4-piston brakes
Moterra Neo Carbon LT 2
Breaking Boundaries
With the new Bosch Performance Line CX & 750Wh battery, getting there was the easy part - now it's time for the fun! With 170mm/165mm of travel, piggy back shock and burly build, it's ready to give as much as you are.
Where it thrives
Whatever and wherever you didn't think possible
What it's built for
Handling, Traction, Efficiency, Durability
Highlights
- Proportional Response Tuned carbon frame, 165mm travel / RockShox Zeb Select fork, 170mm travel
- Bosch SmartSystem - 750wh battery & Performance CX motor
- Shimano XT/SLX 12-speed drivetrain / Magura MT5 4-piston brakes
| Shared across all builds | |
|---|---|
| Shared across every Moterra on this page | |
| Sizes | SM, MD, LG, XL |
| Suspension tuning | Proportional Response — each frame size gets its own kinematics |
| Motor family | Bosch Performance Line CX |
| Battery | removable, weatherproof, flip-open charge port |
| Important | |
| This page covers several different Moterra models. Travel, frame material, wheel setup and battery all vary by build — check the This Build panel above for the bike you have selected. | |
Moterra Neo 3
Details
- Platform: Moterra Neo
- Model Name: Moterra Neo 3
- Model Code: C65372U
Frameset
- Frame: Moterra Neo, SmartForm C1 Alloy, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, injection molded skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, tapered headtube, 18mm two-bolt kickstand mount, integrated rear rack mounts
- Fork: RockShox Yari RC, 150mm, 15x110mm Boost, 44mm offset
- Headset: Integrated Sealed Bearing, 1-1/8" - 1.5
- Rear Shock: RockShox Deluxe Select, DebonAir, 2-Pos mode adjust, adjustable rebound
E-System
- Drive Unit: Bosch Performance Line CX 250W with 85NM of Torque
- Battery: Bosch PowerTube, 750Wh
- Charger: Bosch 4A
- Display: Bosch Kiox 300 w/ LED remote
Drivetrain
- Rear Derailleur: Shimano XT
- Shifters: Shimano Deore M6100, 12-speed
- Chain: Shimano Deore 6100, 12-speed
- Crank: FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
- Rear Cogs: Shimano Deore M6100, 10-51, 12-speed
Brakes
- Brakes: Shimano MT420 4-piston hydraulic disc, 203/203mm rotors
- Brake Levers: Shimano MT401 hydraulic disc
Wheels
- Rims: WTB ST i30 TCS, 32h, tubeless ready
- Spokes: Stainless Steel, 14g
- Tire Size: 2.6
- Wheel Size: 29
- Hubs: (F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
- Tires: (F) Maxxis Minion DHF, 29x2.6", EXO, tubeless ready / (R) Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
- Front Tire: Maxxis Minion DHF, 29x2.6", EXO, tubeless ready
- Rear Tire: Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
Components
- Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
- Stem: Cannondale 3, 6061 Alloy, 31.8, 0°
- Grips: Fabric FunGuy
- Saddle: Fabric Scoop Shallow Sport, steel rails
- Seatpost: TranzX dropper, internal routing, 31.6, 130mm (S), 150mm (M-XL)
Extra
- Extra 1: Pre-installed light cable
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Moterra 4+
Moterra Neo Carbon 1
Details
- Platform: Moterra Neo
- Model Name: Moterra Neo Carbon 1
- Model Code: C25172U
Frameset
- Frame: Moterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5� – 1.8� tapered headtube, 18mm two-bolt kickstand mount
- Fork: RockShox Lyrik Select+, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 44mm offset
- Headset: Acros integrated sealed bearing, tapered
- Rear Shock: RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound
E-System
- Drive Unit: Bosch Performance Line CX 250W
- Battery: Bosch PowerTube, 750Wh
- Charger: Bosch 4A
- Display: Bosch Kiox 300 w/ LED remote
Drivetrain
- Rear Derailleur: Shimano XTR
- Shifters: Shimano XT, 12-speed
- Chain: Shimano XT, 12-speed
- Crank: FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
- Rear Cogs: Shimano XT, 10-51, 12-speed
Brakes
- Brakes: Shimano XT 8120 4-piston hydraulic disc, 203/203mm RT76 rotors
- Brake Levers: Shimano XT hydraulic disc
Wheels
- Rims: WTB KOM Trail i30 TCS, 32h, tubeless ready
- Spokes: DT Swiss Champion
- Tire Size: 2.6
- Wheel Size: 29
- Hubs: (F) Formula 15x110mm thru-axle / (R) DT Swiss, 12x148mm thru-axle
- Tires: (F) Maxxis Minion DHF, 29x2.6", EXO, tubeless ready / (R) Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
- Front Tire: Maxxis Minion DHF, 29x2.6", EXO, tubeless ready
- Rear Tire: Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
Components
- Handlebar: HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm
- Stem: Cannondale 2, 6061 Alloy, 35mm, 0°
- Grips: Fabric FunGuy
- Saddle: Fabric Scoop Shallow Elite, cro-mo rails
- Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
Extra
- Extra 1: Lezyne Super HB E1000 w/ remote high beam switch
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Moterra Neo Carbon 1
Details
- Platform: Moterra Neo
- Model Name: Moterra Neo Carbon 1
- Model Code: C65121M SMU
Frameset
- Frame: 160mm travel, BallisTec Carbon Front Triangle, SmartForm C1 Alloy Swingarm, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, Ai offset drivetrain, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
- Fork: RockShox Zeb Ultimate, Charger 2.1 RC2, 160mm, DebonAir, 15x110, 51mm offset
- Headset: Integrated Sealed Bearing, Tapered
- Rear Shock: RockShox Deluxe Select+ RT, DebonAir
E-System
- Drive Unit: Bosch Performance Line CX 250W
- Battery: Bosch PowerTube, 625Wh
- Charger: Bosch 4A
- Display: Bosch Kiox
Drivetrain
- Rear Derailleur: SRAM X01 Eagle
- Shifters: SRAM GX Eagle, single click, 12-speed
- Chain: SRAM XX1 Eagle, Rainbow, 12-speed
- Crank: FSA Bosch E-bike w/ custom Ai offset, 160mm, 34T
- Rear Cogs: SRAM XX1-Eagle Rainbow, 10-52, 12-speed
Brakes
- Brakes: Magura MT7 4-piston hydraulic disc, Magura MDR-P 220/203mm, 6-bolt rotors
- Brake Levers: Magura MT7 Trail HC hydraulic disc
Wheels
- Front Hub: Formula, 15x110mm
- Rear Hub: SRAM MTH 700, 12x148, XD Driver
- Brake Type: Disc
- Rims: WTB KOM Trail i30 TCS, 32h, tubeless ready
- Spokes: DT Swiss Champion
- Tire Size: 2.6
- Wheel Size: 29
- Tires: (F) Maxxis Assegai, 27.5/29x2.6", dual compound, EXO, tubeless ready / (R) Maxxis DHR II, 27.5/29x2.6", 3C, EXO+, tubeless ready
- Front Tire: Maxxis Assegai, 27.5/29x2.6", dual compount, EXO, tubeless ready
- Rear Tire: Maxxis DHR II, 27.5/29x2.6", 3C, EXO+, tubeless ready
Components
- Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
- Stem: Cannondale 1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 7°
- Grips: Fabric FunGuy
- Saddle: Fabric Scoop Shallow Elite, cro-mo rails
- Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 100mm (S), 125mm (M), 150mm (L-XL)
Extra
- Extra 1: Supernova Mini 2 Pro light
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Moterra Neo Carbon 2
Details
- Platform: Moterra Neo
- Model Name: Moterra Neo Carbon 2
- Model Code: C25272U
Frameset
- Frame: Moterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5� – 1.8� tapered headtube, 18mm two-bolt kickstand mount
- Fork: RockShox Lyrik Select, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 44mm offset
- Headset: Acros integrated sealed bearing, tapered
- Rear Shock: RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound
E-System
- Drive Unit: Bosch Performance Line CX 250W
- Battery: Bosch PowerTube, 750Wh
- Charger: Bosch 4A
- Display: Bosch Kiox 300 w/ LED remote
Drivetrain
- Rear Derailleur: Shimano XT
- Shifters: Shimano SLX, 12-speed
- Chain: Shimano SLX, 12-speed
- Crank: FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
- Rear Cogs: Shimano SLX, 10-51, 12-speed
Brakes
- Brakes: Shimano MT520 4-piston hydraulic disc, 203/203mm RT64 rotors
- Brake Levers: Shimano MT501 hydraulic disc
Wheels
- Rims: WTB ST i30 TCS, 32h, tubeless ready
- Spokes: DT Swiss Champion
- Tire Size: 2.6
- Wheel Size: 29
- Hubs: (F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
- Tires: (F) Maxxis Minion DHF, 29x2.6", EXO, tubeless ready / (R) Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
- Front Tire: Maxxis Minion DHF, 29x2.6", EXO, tubeless ready
- Rear Tire: Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
Components
- Handlebar: Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5° rise, 800mm
- Stem: Cannondale 2, 6061 Alloy, 35mm, 0°
- Grips: Fabric FunGuy
- Saddle: Fabric Scoop Shallow Sport, steel rails
- Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
Extra
- Extra 1: Pre-installed light cable
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Moterra Neo Carbon 2
Details
- Platform: Moterra Neo
- Model Name: Moterra Neo Carbon 2
- Model Code: C65221M SMU
Frameset
- Frame: 160mm travel, BallisTec Carbon Front Triangle, SmartForm C1 Alloy Swingarm, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, Ai offset drivetrain, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
- Fork: RockShox Zeb Select, Charger RC, 160mm, DebonAir, 15x110, 51mm offset
- Headset: Integrated Sealed Bearing, Tapered
- Rear Shock: RockShox Deluxe Select R, DebonAir
E-System
- Drive Unit: Bosch Performance Line CX 250W
- Battery: Bosch PowerTube 625Wh
- Charger: Bosch 4A
- Display: Bosch Purion
Drivetrain
- Rear Derailleur: SRAM GX Eagle
- Shifters: SRAM NX Eagle, single click, 12-speed
- Chain: SRAM NX Eagle, 12-speed
- Crank: FSA Bosch E-bike w/ custom Ai offset, 160mm, 34T
- Rear Cogs: SRAM XG-1275 Eagle, 10-52, 12-speed
Brakes
- Brakes: Magura MT5 4-piston hydraulic disc, Magura MDR-P 220/203mm, 6-bolt rotors
- Brake Levers: Magura MT5 Trail HC hydraulic disc
Wheels
- Front Hub: Formula 15x110
- Rear Hub: SRAM MTH 700, 12 x 148, XD Driver
- Brake Type: Disc
- Rims: WTB ST i29 TCS, 32h, tubeless ready
- Spokes: DT Swiss Champion
- Tire Size: 2.6
- Wheel Size: 29
- Tires: (F) Maxxis Assegai, 27.5/29 x 2.6", dual compount, EXO, tubeless ready / (R) Maxxis DHR II, 27.5/29 x 2.6", 3C, EXO+, tubeless ready
- Front Tire: Maxxis Assegai, 27.5/29 x 2.6", dual compount, EXO, tubeless ready
- Rear Tire: Maxxis DHR II, 27.5/29 x 2.6", 3C, EXO+, tubeless ready
Components
- Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
- Stem: Cannondale 1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 7°
- Grips: Fabric FunGuy
- Saddle: Fabric Scoop Shallow Sport, steel rails
- Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 100mm (S), 125mm (M), 150mm (L/XL)
Extra
- Extra 1: Preinstalled light cables
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Moterra Neo Carbon LT 1
Details
- Platform: Moterra Neo LT
- Model Name: Moterra Neo Carbon LT 1
- Model Code: C25472U
Frameset
- Frame: Moterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 165mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5� – 1.8� tapered headtube, 18mm two-bolt kickstand mount
- Fork: RockShox Zeb Select +, Charger RC, 170mm, DebonAir, 15x110mm, 44mm offset
- Headset: Acros integrated sealed bearing, tapered
- Rear Shock: RockShox Deluxe Select+, Coil, 2-Pos mode adjust, adjustable rebound
E-System
- Drive Unit: Bosch Performance Line CX 250W
- Battery: Bosch PowerTube 750Wh
- Charger: Bosch 4A
- Display: Bosch Kiox 300 w/ LED remote
Drivetrain
- Rear Derailleur: Shimano XT
- Shifters: Shimano XT, 12-speed
- Chain: Shimano XT, 12-speed
- Crank: FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
- Rear Cogs: Shimano XT, 10-51, 12-speed
Brakes
- Brakes: SRAM Code RSC hydraulic disc, 4-piston, CenterLine 220/200mm rotors
- Brake Levers: SRAM Code RSC hydraulic disc
Wheels
- Rims: WTB KOM Trail i30 TCS, 32h, tubeless ready
- Spokes: DT Swiss Champion
- Tire Size: 2.6
- Wheel Size: 29
- Hubs: (F) Formula 15x110mm thru-axle / (R) DT Swiss, 12x148mm thru-axle
- Tires: (F) Maxxis Assegai, 29 x 2.6", 3C, EXO+, tubeless ready, (R) Maxxis DHR II, 27.5 x 2.6", 3C, EXO+, tubeless ready
Components
- Handlebar: HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm
- Stem: Cannondale 2, 6061 Alloy, 35mm, 0°
- Grips: Fabric FunGuy
- Saddle: Fabric Magic Elite Saddle, cro-mo rails
- Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
Extra
- Extra 1: Lezyne Super HB E1000 w/ remote high beam switch
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Moterra Neo Carbon LT 2
Details
- Platform: Moterra Neo LT
- Model Name: Moterra Neo Carbon LT 2
- Model Code: C25572U
Frameset
- Frame: Moterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 160mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5� – 1.8� tapered headtube, 18mm two-bolt kickstand mount
- Fork: RockShox Zeb Select, Charger RC, 170mm, DebonAir, 15x110mm, 44mm offset
- Headset: Acros integrated sealed bearing, tapered
- Rear Shock: RockShox Deluxe Select+, Coil, 2-Pos mode adjust, adjustable rebound
E-System
- Drive Unit: Bosch Performance Line CX 250W
- Battery: Bosch PowerTube, 750Wh
- Charger: Bosch 4A
- Display: Bosch Kiox 300 w/ LED remote
Drivetrain
- Rear Derailleur: Shimano XT
- Shifters: Shimano SLX, 12-speed
- Chain: Shimano SLX, 12-speed
- Crank: FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
- Rear Cogs: Shimano SLX, 10-51, 12-speed
Brakes
- Brakes: Magura MT5 4-piston hydraulic disc, Magura MDR-P 220/203mm, 6-bolt rotors
- Brake Levers: Magura MT5 Trail HC hydraulic disc
Wheels
- Rims: WTB ST i30 TCS, 32h, tubeless ready
- Spokes: Stainless Steel, 14g
- Tire Size: 2.6
- Wheel Size: 29
- Hubs: (F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
- Tires: (F) Maxxis Assegai, 29x2.6", 3C, EXO+, tubeless ready, (R) Maxxis DHR II, 27.5x2.6", 3C, EXO+, tubeless ready
Components
- Handlebar: Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5° rise, 800mm
- Stem: Cannondale 2, 6061 Alloy, 35mm, 0°
- Grips: Fabric FunGuy
- Saddle: Fabric Scoop Shallow Sport, steel rails
- Seatpost: Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
Extra
- Extra 1: Pre-installed light cable
Please note that, based on component availability and other factors, specifications are subject to change without notice.
Free shipping on orders over $150. Returns accepted within 30 days in original condition. Bikes must be unridden and in original packaging.
Visit us at 1 W Main St, Midway, UT. Demo bikes and skis available — call (435) 654-0500 to reserve.
